Economical -86℃ Ultra Low Temperature Freezer

This -40℃ chest freezer is a top of the range product designed to meet the needs of laboratories, research facilities and hospitals.

  • Model : UFZ-86V30; UFZ-86V110E; UFZ-86V160E; UFZ-86V940
  • Capacity (L) : 28 / 108 / 158 / 938
  • Internal Size (mm) : 270x265x400 / 460x460x510 / 460x455x800 / 1000x700x1335
  • Shelves / Drawers (Qty) : 1 Shelves/ 2 Shelves / 2 Shelves / 3 Shelves
  • Temperature Range (℃) at RT.10~32℃ : -40~-86, adjustable

Share the product

Our -86°C chest Freezer uses advanced refrigeration technology to provide a stable -86°C low-temperature environment. Designed for use in laboratories and healthcare organisations, it ensures that samples and items are stored at optimum temperatures. It combines excellent performance with an environmentally friendly and energy-efficient design, making it indispensable equipment in the scientific and medical fields.

-86℃ Ultra Low Temperature Freezer Feature:

  1. Adopt high performance V.I.P. (Vacuum Insulation Panel) heat insulation board to improve temperature stability.
  2. Adopts hybrid refrigeration system for rapid and stable cooling.
  3. Separate storage compartments to minimize frost formation inside the box.
  4. Lockable universal casters for easy mobility.
  5. Removable inner door for easy defrosting and cleaning.

-86℃ Ultra Low Temperature Freezer Specifications:

Model UFZ-86V30 UFZ-86V110E UFZ-86V160E UFZ-86V940
Capacity (L) 28 108 158 938
Size (WxDxH) Internal (mm) 270x265x400 460x460x510 460x455x800 1000x700x1335
External (mm) 470x490x1120 700x730x1260 700x700x1580 1240x1000x2000
Temperature Range (℃) -40~-86℃, adjustable -40~-86℃,  adjustable -40~-86℃,  adjustable -40~-86℃,  adjustable
Sensor PTC PTC PTC PTC
Controller Microprocessor Microprocessor Microprocessor Microprocessor
Cooling
System
Refrigerant Mixed with CFC free Mixed with CFC free Mixed with CFC free Mixed with CFC free
Defrost Manual Manual Manual Manual
Compressor (Qty) SECOP/1 SECOP/1 SECOP/1 SECOP/2
Display LED LED LED LED
Audible&
Visible Alarm
High/Low Temperature Standard Standard Standard Standard
Abnormal Ring Temperature Optional (LCD) Optional (LCD) Optional (LCD) Optional (LCD)
Sensor Failure Standard Standard Standard Standard
Condenser Dirty Blockage Optional (LCD) Optional (LCD) Optional (LCD) Optional (LCD)
Low Battery Optional (LCD) Optional (LCD) Optional (LCD) Optional (LCD)
Power Failure Optional (LCD) Optional (LCD) Optional (LCD) Optional (LCD)
Door Ajar Optional (LCD) Optional (LCD) Optional (LCD) Optional (LCD)
Material External Electro-galvanized steel with antimicrobial powder coating Electro-galvanized steel with antimicrobial powder coating Electro-galvanized steel with antimicrobial powder coating Electro-galvanized steel with antimicrobial powder coating
Inner Door 304 stainless steel 304 stainless steel 304 stainless steel 304 stainless steel
  Casters Standard Standard Standard Standard
Temperature Recorder Optional Optional Optional Optional
Test Hole (Qty) /Diameter (mm) 1/18 1/18 1/18 1/18
Shelves / Drawers (Qty) Shelves / 1 Shelves / 2 Shelves / 2 Shelves / 3
Sound Emission (dB) 60 60 60 60
Electricity Voltage / Frequency 220V, 50/60Hz; 110V, 60Hz 220V, 50/60Hz; 110V, 60Hz 220V, 50/60Hz; 110V, 60Hz 220V, 50/60Hz; 110V, 60Hz
Consumption (W) 400 480 500 1020
N.W. / G.W. (kg) 66/91 107/137 123/153 320/350
Shipping Size (WxDxH)(mm) 550x590x1270 780x830x1410 780x800x1730 1320x1100x2150

Advantages of -86℃ Ultra Low Temperature Freezer:

  1. High-quality compressors ensure more stable freezing temperatures and energy savings
  2. Designed for superior performance in accordance with laboratory requirements
  3. Quiet operation ensures that operators are not disturbed in the laboratory.
  4. Intuitive, easy-to-read control panel makes the -86°C Chest Freezer simple to use.
  5. Multiple safety features to protect your samples in a stable manner

Application of -86℃ Chest Freezer:

  1. Laboratory: Suitable for storing biological samples, reagents and research materials to ensure the accuracy and reliability of experimental data.
  2. Medical Institutions: Store vaccines, plasma and other pharmaceutical products require cryopreservation to ensure activity and stability.
  3. Scientific research projects: Low temperature storage needs of various scientific research projects, ensuring the integrity of samples.
  4. Industrial applications: For cryogenic storage of industrial materials and products to ensure their quality and performance.

-86℃ Ultra Low Temperature Freezer Packing:

Our -86℃ ultra low temperature freezer is packed in sturdy packaging materials to ensure safety during transport. Each freezer is double-protected with high-strength foam and wooden crates to avoid collision or damage during transport.

WHY SCITEK

  1. 36 Months Limited Warranty
  2. CE & FDA Standards
  3. 1-2 Days Handling and 7-30 Days Shipping
